Bandwidth: 1MHz~20MHz
Receiving Gain: 72dB, Step Pace 1dB, 6dB
Average: Average Number Of Times 0 To 64 Automatically Adjusted
Update Rate: 4Hz, 8Hz, 16Hz
Filter: Broadband, 5m, 10m, 15m
Probe Type: Single Crystal, Double Crystal
Pulse Mode: Square Waves, Two-sided Waves
Transmit Voltage: 25V~300V, 25V Step Pace
Pulse Width: 25ns~300ns, 5ns Step Pace
Pulse Frequency: 400Hz-3200Hz Auto-adjustment
Specialized Function :A-Scan, B-Scan
Calibration Mode: Automatic Zero Point Calibration, Automatic Sound Velocity Calibra- tion
View Mode: Normal, Difference, Maximum Value Capture
Measuring Range: 0.15~3200mm(Longitudinal Wave Carbon Steel)
Detection Mode: Full Wave, Positive Half Wave, Negative Half Wave, RF, Invert to RF
Measurement Mode: P-E(Pulse-Echo), E-E(Echo-Echo), I-E(Interface-Echo), ME-E(Multiple echo)
Detection Range: 0X-25mm(Steel), 1X-100mm(Steel), 2X-200mm(Steel), 3X-400mm(Steel), 4X-800mm(Steel), 5X-1600mm(Steel), 6X-3200mm(Steel)
Data Storage: 520 Files Can Be Saved, Each File Can Record 252 Sets Of Thickness Values, For A Total Of 130,000 Sets.
Auxiliary Functions: Auto Gain, Auto Range, Auto Blanking E, Auto Freeze, Auto Average, Auto Shutdown (Hibernation),Buzzer Alarm, Upper Computer Communication, Backlight Adjustment
Unit: Metric System, English System
Language: Chinese，English
Probe Interface: Dual LEMO-00 C5
Net Weight: 228g, No Battery
Battery: Two 1.5V AA Batteries
Output Interface: MINI USB，Data Export To The Host Computer
Dimensions :153mm×76mm×37mm
Display Screen: 2.4-inch 320×240 IPS_LCD
Working Temperature: -10°C~55°C
Standard Delivery
Main Unit: 1PC
Alkaline Battery: 2 PCS
Coupling Agent: 1 Bottle
Screwdriver: 1PC
Instrument Case: 1PC
Optional Delivery
Software: TG-SW
USB Cable: TG-USB
Double Crystal 5M Probe: TP0510400
Single Crystal 5M Probe: TP1514302
Single Crystal 15M Probe: TP1507025
