Detectable workpiece material: carbon steel, cast steel, alloy steel, stainless steel, copper, aluminum, titanium and other conductor materials
Measurement range: 1.5-240.0mm
The maximum value of the measurement range is affected by the properties of the measured material, sound attenuation coefficient, surface conditions and other factors
Error range of measuring equipment: When the thickness of workpiece is less than 10mm, the error is 0.05mm; when the thickness is more than 10mm, the error is + (0.01 + H / 200) mm (H is the thickness of workpiece)
Receiving gain: ≤ 100dB
Normal temperature probe: ≤ 80 ℃, 4MHz, mainly used to detect fine-grained materials, such as low carbon steel, aluminum, etc., with a maximum liftable clearance of 3mm
High temperature probe: ≤ 800 ℃, 4MHz, mainly used to measure ferromagnetic fine-grained materials, such as low carbon steel, with a maximum liftable clearance of 2mm
Lift-off effect: actual lift-off distance is related to material properties and degrees), anti-rust film, salt deposits or any other insulating coating (oil, varnish, porcelain, plastic, etc.) can be used as operating clearance
The minimum diameter (curvature) of the workpiece that can be detected is 8mm
The maximum tilt angle of the probe: 25°
Probe field excitation method: permanent magnet
Type of sound wave: shear wave
Power supply: built in lithium battery, working time not less than 2.5 hours
The normal working temperature range of the host: -10~+50℃
Host storage temperature range: 0~+40℃
Host weight: 250g (with normal temperature probe)
Dimensions of the host: length 151mm x width 76mm x thickness 37mm
Standard Delivery
Main Unit: 1 pc
Probe: Optional
Couplant: 1 bottle
3.7V Rechargeable Batteries: 4 pcs
Charging Data Cable: 1 pc
Charging Plug: 1 pc
Instrument Case: 1 pc
Optional Delivery
Normal Temperature Probe: ETP044232
High Temperature Probe: EHTP043340
Large Diameter Probe: ETP044060
Small Diameter Probe: ETP041336
