Measuring range:
X-axis 900mm
Y-axis 1000mm
Z-axis 600mm
Resolution: 0.0001mm (0.1μm)
Guide system: Linear guide on each axis
Operating speeds:
- CNC Mode Drive speed: each axis 8 to 500mm/s; all axes 866mm/s
Measuring speed: 1 to 20mm/s
- Joystick mode: 0 to 80mm/s (High Speed); 0 to 3mm/s (Low Speed); 0.05mm/s (Fine Speed)
Maximum drive acceleration: Each axis 5,000mm/s2; all axes 8,660mm/s2
Scale type: Linear encoder
Workpiece:
- Maximum height: 800mm
- Maximum mass: 150kg
Mass of machine (including the mounting stand and controller): 4130kg
Operating environment: 5 to 35°C
Probe used: SP25M (Stylus: ø4x50mm); TP7M (Stylus: ø4×20mm)
