Digital/Analog:Digital
Inch-Metric: Inch/Metric
Range: 0.5"/12.7 mm
Digital step:
0.00002"/0.00005"/0.0001"/0.0005"
0.0005 mm/0.001 mm/0.01 mm
Max. Permissible Error E MPE (Total Range): ±0.00012"/0.003 mm
H MPE (Hysteresis): 0.00008"/0.002 mm
R MPE (Repeatability): 0.00008"/0.002 mm
Measuring force MPL: ≤1.5 N
Protection: IP42
Type: ASME/ANSI/AGD Standard
Mass: 165 g
Display: LCD, character height 11 mm, 330° rotatable
Max. response speed: Unlimited
Measurement frequency (MAX/MIN/RANGE): 50 times/s
Alarm: Low voltage, setting errors, sensor error, display overflow a.s.o.
Stem ∅: 9.52 mm
Contact point: Carbide ball, thread: No.4-48UNF
Power supply: 1 battery CR2032
Battery life: Approx. 2700 hours (continuous use)
Digital Scale: Electrostatic capacitance type absolute linear encoder
ON/OFF: Yes
ABS / INC (INC ZERO): Yes
Function lock:Yes
GO/±NG judgement: Yes
DATA/HOLD: Yes
Auto Power OFF setting:Yes
Counting direction switchable: Yes
Customizing keys: Yes
Calibration warning function: Yes
Low voltage alarm: Yes
Digital step switchable:Yes
Digimatic data output: Yes
Digimatic S1 Bidirectional interface: Yes
Analog bar resolution switchable:Yes
Inch/Metric switchable:Yes
