Measuring range:
X 570 mm
Y 500 mm
Z 500 mm
Max. Permissible Length Measurement Error (ISO 10360-2: 2009): (2.2+3L/1000) µm*2 L: Measured length (unit: mm)
Drive speed: 5 - 350 mm/s (max. combined speed 606 mm/s) in CNC MODE
Drive acceleration: 1556 mm/s2 (max. combined acceleration 2695 mm/s2)
Measuring table capacity: Maximum workpiece height 660 mm
Maximum loading: 120 kg
Accuracy guaranteed temperature: 10 ºC - 40 ºC
Mass (including the control device and installation platform): 655 kg
