Traverse:
X = 200 mm
Y = 800 mm
Z2 = 500 mm
Detector hold type (Essential option): Standard; Long type; Rotary type
Measuring speed: 0.02 - 2 mm/s
Drive speed: CNC mode: max. 200 mm/s; Joystick mode: 0 - 50 mm/s
Traverse straightness:
X = 0.5 µm / 200 mm (standard)
X = 0.7 µm / 200 mm
(long-type detector)
X = 0.5 µm / 200 mm
(rotary-type detector)
Y = 0.5 µm / 50 mm; 2 µm / 800 mm (standard)
Y = 0.7 µm / 50 mm; 3 µm / 800 mm
(long-type detector)
Y = 0.7 µm / 50 mm; 3 µm / 800 mm
(rotary-type detector)
Inclining range: -45° (CCW) to +10° (CW)
Range: 800 µm; 80 µm; 8 µm (bis zu 2,4 mm mit einem optionalen Taster)
Standard: EN ISO, VDA, JIS, ANSI and customize setting
Profiles: Primary Profile (P), Roughness Profile (R), Waviness (W), MOTIF (R, W) and more
Loading weight: 300 kg
