Pitch: 6.5 mm (0.256 in)
Application: Wire-to-Board
Row Spacing: 6.5 mm (0.256 in)
Unit Weight: 2.884 g
Housing Color: Blue
Contact Gender: Pin (Male)
Current Rating: 10 A
Mounting Angle: Straight
Mounting Style: Kinked Pin
Number of Rows: 2 Row
Voltage Rating: 600 VAC/DC
Contact Plating: Tin
Contact Material: Copper Alloy
Housing Material: Polyamide (PA)
Termination Style: Solder Pin
Mating Post Length: 8.85 mm (0.348 in)
Flammability Rating: UL 94 V-0
Number of Positions: 4 Position
Insulation Resistance: 1 GOhms
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 40 C
