Pitch: 1.5 mm (0.059 in)
Wire Gauge: 24 AWG
Application: Wire-to-Board, Signal
Unit Weight: 1.147 g
Contact Type: Socket (Female)
Housing Color: Beige
Latching Type: Unlatched
Contact Gender: Socket (Female)
Current Rating: 2 A
Mounting Angle: Straight
Mounting Style: Kinked Pin
Number of Rows: 1 Row
Voltage Rating: 100 V
Contact Plating: Tin
Contact Material: Tin
Housing Material: Polyamide (PA)
Termination Style: Solder Pin
Flammability Rating: UL 94 V-0
Number of Positions: 14 Position
Insulation Resistance: 500 MOhms
Termination Post Length: 3.4 mm (0.134 in)
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 40 C
