Pitch: 2.5 mm (0.098 in)
Application: Wire-to-Board, Signal
Housing Color: Black
Contact Gender: Pin (Male)
Current Rating: 3 A
Mounting Angle: Right Angle
Mounting Style: Through Hole
Number of Rows: 1 Row
Voltage Rating: 250 VAC/DC
Contact Plating: Tin
Contact Material: Phosphor Bronze
Housing Material: Polyamide (PA)
Termination Style: Solder Pin
Mating Post Length: 4 mm (0.157 in)
Number of Positions: 10 Position
Insulation Resistance: 1 GOhms
Termination Post Length: 3.4 mm (0.134 in)
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 55 C
