GENERAL SPECIFICATIONS
- Frequency Range: 403-470MHz
- Channel Capacity: 64
- RF Output Power: 1-100W
- Dimensions (H x W x D): 3.5 x 19 x 17.25 in (89 x 483 x 438 mm)
- Weight: 31 lbs (14.1 kg)
- Input Voltage (AC): 100-240 Vac, 47-63Hz
+ Current (standby) 110/240V: 0.25 / 0.3 A
+ Current (transmitting at 100 W) 110/240V: 2.0 / 1.1 A (typical)
- Input Voltage (DC): (11.0 - 15.5 V) / 24 V (21.6 - 32.0 V)
+Current (standby), 24V: 0.5 A
+Current (transmitting at 100 W), 24 V: 8.2 A (typical)
- Operating Temperature Range: -22 to +140 °F (-30 to +60 °C)
- Humidity: RH of 95%, non-condensing at 50 °C (122 °F)
- Max Duty Cycle: 100%
- Digital Vocoder Type: AMBE+2™
- Battery Charger Capacity (12 / 24 V): 5A
RECEIVER
- Frequency Range: 403-470MHz
TRANSMITTER
- Frequency Range: 403-470MHz
- RF Output Power: DC (24 V) or AC 1 - 100 W DC (12 V) 1 - 50 W
Notes:
- Compatible with IPSC infrastructure
- Optional acessories: copyrights for single-point trunking (Capacity Plus), multi-point trunking (Linked Capacity Plus); Controller trunking
- Excluding acessories: Duplexer, Patch cable, antenna, connector, coaxial cable, etc.
