Power Supply: 115/230VAC, 50/60 Hz
Test Current:
25A, 10A, 5A, 1A, 100mA & 10mA
Open-Circuit Test Voltage: 60 VDC
Burden: 1500W
Resistance Measurement Range
Accuracy: ±(0.1% of rdg. ± 5counts)
| Test Current | Range (Ω) | Resolution (Ω) | Maximum Display (Ω) | ||||
| 25A | 10A | 1A | 100mA | 10mA | |||
| √ | 200uΩ | 0.01uΩ | 199.99uΩ | ||||
| √ | √ | 2mΩ | 0.1uΩ | 1.9999mΩ | |||
| √ | √ | √ | 20mΩ | 1uΩ | 19.999mΩ | ||
| √ | √ | √ | √ | √ | 200mΩ | 10uΩ | 199.99mΩ |
| √ | √ | √ | √ | 2Ω | 0.1mΩ | 1.9999Ω | |
| √ | √ | √ | 20Ω | 1mΩ | 19.999Ω | ||
| √ | √ | 200Ω | 10mΩ | 199.99Ω | |||
| √ | 2000Ω | 0.1Ω | 1999.9 Ω | ||||
| Test Current | Range (Ω) | Resolution (Ω) | Maximum Display (Ω) |
| 5A | 4 mΩ | 0.1 µΩ | 4.0000 mΩ |
| 40 mΩ | 1 µΩ | 40.000 mΩ | |
| 400 mΩ | 10 µΩ | 400.00 mΩ | |
| 4 Ω | 0.1mΩ | 4.0000 Ω |
General
Principle: 4 wire measurement
Measurement Channel: 3 resistance & 1 current channel
Temperature Channel: 2 Channel
Temperature Range: 0 – 100 °C
Display: LCD
Indication: LED & veep during test on, & discharge
PC Interface: USB
Internal memory: 2000 test readings
Printer: Inbuilt thermal printer
Safety & Standards
Ingress Protection: IP 54
CE Certification
Safety: Compliant with IEC 61010-1
EMC: Compliant with IEC 61326-1
Environmental
Conditions Operating Temperature: 0°C to 55°C
Storage Temperature: -10°C to 60°C
Humidity: 95% RH, Non condensing
Physical Specifications
Dimensions (L×W×D) mm: 525 x 437 x 213
Weight: 15 kg
Software Details
Type: Windows based analytical software
Data Transfer: Real-time data transfer
Features: Online data acquisition
Graph plotting for heat run test & OLTC dynamic test
Remote operation
Test report generation
Standard Accessories
15 meters measuring test lead set
Mains power cord
Short links – 2Nos.
Earthing lead
User manual
Calibration certificate
Carry case for test leads
Optional Accessories
OLTC probe
PC Software
USB cord
Temperature sensor
Bluetooth application via cloud based Motware application
