MULTI FCM-400 Flexible AC/DC Current Tester (3A/30A/300A)

Clamp sensor/Current detection part

Inside diameter of CT: φ450mm

Lead length: Approx.2m (From measuring unit to CT)

Measuring part

Mesuring function: AC (RMS)/DC current

Measuring ranges: AC/DC 3A/30A/300A

Sampling rate: 2 times/sec

Over range indication: "OL" mark on LCD

Data hold indication: "DH" mark on LCD

Low battery indication: "B" mark on LCD

Auto power off: Approx. 10 minutes after power on

General specification

Limitation of circuit voltage: Less than AC 600V

Operating temperature: 0～45℃, < 85%RH (without condensation)

Storage temperature: -10～60℃, < 70%RH (without condensation)

Withstanding voltage: AC 2200V/1 minute

Power supply: 1.5V(AA size or UM-3) battery×6

Dimension: Main unit:159(W)×105(H)×53(D)mm
