MultiTech MTJ-2831 Digital LCR Meter (50Hz-200kHz)

Basic Measurement Readiness:

+ LCRZ:  0.05%;

+ DCR:  0.10%

+ Calibration Conditions: Preheat time≥ 30 min; Environment temperature : 23±5°C; Signal voltage: 1V; Vrms Cleared: after OPEN, SHORT Measuring cable length: 0m

Test Signal Frequency: 50Hz-200kHz; 37 points

Signal Impedance Source Output: 30Ω,100Ω optional,±1%@1kHz

AC Test Signal Level:

+ Normal: 10mV-2Vrms; Min. resolution: 10mV, accuracy: 10% x set voltage + 2mV 100μA-20mArms minimum resolution:0.1mA

+ Constant Level: -

DCR Test Signal Level:  1V DC

DC Bias Voltage Source: -

LCR Meter Test Parameters: L,C,R,|Z|,D,Q,|Y|,G,X, θd, θr, RDC, Vm, Im, ∆%

DCR Display Range:  0.00001Ω~999.999MΩ

LCR Parameter Display Range:

|Z|, R, X: 0.00001Ω~99.9999MΩ

|Y|, G, B: 0.00001µS-99.9999S

C: 0.00001pF-9.9999F

L: 0.00001µH-99.9999H

∆%: -999.999%~999.999%

D: 0.00001-9.99999

Q: 0.00001-99999.9

θ(DEG): -179.999º-179.999º

θ(RAD): -3.14159-3.14159

Display Number of Digits: 5

Equivalent Circuit: Series connection, parallel connection

Range Mode: Auto, keep

Trigger Mode: Internal, manual, external, bus
