Length: 21.8 mm
Diameter: 29.8 mm
Core Type: Bobbin
Q Minimum: 28
Shielding: Unshielded
Tolerance: 10 %
Inductance: 1.5 mH
Application: Magnetic
Termination: Standard
Unit Weight: 50 g
Lead Spacing: 28.8 mm
Core Material: Ferrite
Lead Diameter: 0.75 mm
Mounting Style: PCB Mount
Test Frequency: 1 kHz
Termination Style: Radial
Maximum DC Current: 1.7 A
Maximum DC Resistance: 374 mOhms
Self Resonant Frequency: 700 kHz
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
