Width: 9.9 mm (0.39 in)
Height: 6.9 mm (0.272 in)
Length: 11.6 mm (0.457 in)
Industry: Medical, Industrial
Application: Industrial
Unit Weight: 1.090 g
Output Power: 750 mW
Input Voltage: 4.5 V to 5.5 V
Mounting Style: Through Hole
Isolation Voltage: 1 kV
Number of Outputs: 1 Output
Input Voltage - Max: 5.5 V
Input Voltage - Min: 4.5 V
Input Voltage, Nominal: 5 V
Output Current-Channel 1: 150 mA
Output Voltage-Channel 1: 5 V
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
