Width: 6 mm (0.236 in)
Height: 10 mm (0.394 in)
Length: 19.5 mm (0.768 in)
Industry: Industrial
Dimensions: 19.5 mm x 6 mm x 10 mm
Application: Industrial
Unit Weight: 1.090 g
Output Power: 750 mW
Input Voltage: 4.5 V to 5.5 V
Mounting Style: Through Hole
Isolation Voltage: 3 kV
Number of Outputs: 2 Output
Input Voltage - Max: 5.5 V
Input Voltage - Min: 4.5 V
Input Voltage, Nominal: 5 V
Output Current-Channel 1: 31 mA
Output Current-Channel 2: 31 mA
Output Voltage-Channel 1: 12 V
Output Voltage-Channel 2: - 12 V
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
