Display screen: 3.5″ full angle TFT display screen
Infrared image resolution: 320 × 240
visible image resolution 300,000 pixel
Field angle/shortest focus length: 56° x 42°/ 0.15m
Display screen resolution: 640*480
Thermal sensitivity: 0.07°C
Temperature measurement range: -20°C to 450°C (-4°F to 842°F)
Measurement accuracy: ±2% digital / ±2°C
Emissivity: Adjustable from 0.01 to 1.0
Frame rate of thermal images: 9 Hz
Wavelength coverage: 8 - 14um
Focus mode: Fixed
Color palette: Rainbow, iron oxide red, cold color, black & white, white
& black
View option: The integration of thermal image with 25% step length
and visible image.
Storage medium: Built-in 3G (above 20,000 image stored)
File format JPG
USB Micro USB 2.0
Power supply: Built-in chargeable 26650 battery
Dimension (LxWxH): 97mm × 129mm × 256mm
Work temperature: 0°C to 45°C
Storage temperature: -20°C to 60°C
Relative humidity: < 85% RH
