maximum test force: 1000kN
Relative error of test force indicating value: ≤indicating value±1%
Test force measurement range: 1%～100%F.S
Test force resolution: 0.01KN
Equivalent stress control range: 2～60 N/mm2·S-1
Stress rate error: ≤±1%
Isokinetic strain control range: 0.00025/s～0.0025/s
Strain rate error: ≤±1%
Deformation measurement range: 0～350mm
Deformation resolution: 0.01mm
Loading rate: 0.02%—2%FS/s；Computer automatic control display
Compression space: 0-350mm
Test area（LW）: 1500x1500mm
Spherical compression pad: Φ356x40mm
Rigid pad: Multiple sizes
Piston stroke: 0-200mm
Machine Size（LWH）: 1700x1700x1980mm
Oil source system（LWH）: 1160x800x940mm
Height of the test area from the ground: 400mm
Frame structure: Four-column, lower oil cylinder, large worktable, high rigidity
Voltage: ～380V±10% 50Hz（Must be grounded reliably）
Machine power: 3.0kW
Machine weight: ≈3200kg
