The maximum impact energy : 10000J
Impact speed :≥7m/s
The installation height of the host: ≤5.5m
Mass error of counterweight weight : ≤±0.5%
The total mass error of the drop weight : ≤1%
Rockwell hardness of hammer blade and supporting surface of support jaw: >HRC56
The radius of curvature of the drop hammer blade : R25.4±2.5mm
The radius of curvature of the support jaws : R14.3±1.59mm
Support span :254+1.5mm
The deviation between the center line of the hammer blade and the center of the span of the support : ±1.5mm
The deviation between the sample centering device and the center line of the sample gap : ≤1.5 mm
The deviation between the lifting height of the drop weight and the standard value :s ≤1.5 mm
sample size : 305×76×(3~40)mm
Dimensions of the testing machine: 1600×2200×5000mm
Motor power: 3.5kw
