Host style: horizontal
Dynamic torque measurement range: 20Nm-2000N.m
Static torque test range: 10NM-1000N.m
Axial force measurement range: 10KN-500KN
Relative error of axial force and torque indicating value: ±1%
Repeatability error of axial force and torque indicating value: < 1%
Measurement range of torsion angle: 0-100000°
Relative error of angle measurement: ±0.5%
Torsion speed: 0-10r/min
Rotation direction: forward rotation, reverse rotation
Protection function: the testing machine has overload protection function
Diameter of testing bolt: M10-M24
Bolt length: 40-200mm (other lengths can be customized)
Power supply: 380V, 50Hz
Motor power is about 3.0KW
