Maximum torque (N.m): 5000
Torque measurement range: 1%～100%FS (full scale)
Testing machine level: better than level 1
Relative error of torque indicating value: ±1%
Torque resolution: 1/300000 of torque
Torsion angle measurement range: 0º-9999º
Relative error of torsion angle indication: ±1%
Torsion angle small resolution: 0.01º
Torsion speed: 3.6-1080º/min stepless speed regulation
Torsional speed relative error: Within ±1.0% of the set value
Collet spacing（mm）: 500
Test rotation direction: uni/bidirectional
Testing machine spindle center height（mm）: ≥120
Specimen diameter: Do according to customer requirements
Motor power（kW）: 4
Voltage: 220V 50Hz /380V 50Hz
