Maximum test force (dynamic and static)kN: ±100 kN
Host frame: Two or four columns
Effective column width（mm）: 635
Test space(mm): 800
Test force measurement range: Dynamic 2%～100%FS
Force Accuracy and Volatility: Better than the indicating value by 1%; the amplitude fluctuation is not greater than ±1%F.S of each file
Test force resolution: 1/250000 yards
Test force indicating value accuracy: Dynamic ±1%; static 0.5%
Displacement measurement range: 100mm(±50mm)
Displacement measurement resolution: 0.001mmm
Displacement indicating value accuracy: Indication value accuracy ±0.5% from 1%
Deformation: Indication value accuracy from 2%, within ±0.5%
Frequency Range: Standard machine 0.01-50HZ (depending on the controller); Static pressure support actuator: 0.01-100HZ
Main waveform: Sine wave, pulse wave, square wave, sawtooth wave, random wave
Aids: Hydraulic forced clamping body with round and flat specimen jaws; Compression aids
