Current: 20A
Power: 2400W
Min operating voltage: 4.5V@20A
CC mode
Range: 0~2A/ 0~20A
Setting Resolution: 0.1mA/ 1mA
Setting Accuracy (23±5℃): 0.05%+0.1%F.S.
CV mode
Range: 0~60V/ 0~600V
Setting Resolution: 1mV/ 10mV
Setting Accuracy: (23±5℃) 0.05%+0.05%F.S.
CP mode
Range: 0~2400W
Setting Resolution: 0.1W
Setting Accuracy (23±5℃): 0.5%+1%F.S
CR mode
Range: 0.56Ω~3000Ω / 11.2Ω~30000Ω
Setting Resolution: 16 bits
Setting Accuracy (23±5℃): 0.35%+1.1mS / 0.35%+0.1mS
Slew Rate
Current: 0.3~20A/ms / 20~1000A/ms
Voltage: 5.0~250V/ms / 250~2500V/ms
Power: 0.3~20A/ms / 20~1000A/ms
Resistance: 0.3~20A/ms / 20~1000A/ms
Voltage Measurement
Range: 0~60V/ 0~600V
Readback Accuracy (23±5℃): 0.05%+0.05%F.S.
Current Measurement
Range: 0~2A / 0~20A
Readback Accuracy (23±5℃):0.05%+0.1%F.S.
Power Measurement
Range: 0~2400W
Readback Accuracy (23±5℃): 0.5%+1%F.S.
Interface: LAN/RS232/CAN
AC Input: Single phase, 220V AC±10%, frequency 47Hz~63Hz
Sampling Frequency: 25Hz
Communication Response Time: ≤10ms
Operating Environment: Altitude: <2000m, relative humidity: 5%~90%RH(non-condensing), atmospheric pressure: 80~110kPa
Temperature: Operating temperature: 0℃~40℃, storage temperature: -20℃~60℃
Net weight: Approx. 23.4kg
Dimension: 3U, 132.5(H)*482.0(W)with handle*612.0(D)mm
