Current: ±5A/CH
Voltage: 15V/CH
Power: 75W/CH
Channels: 8CH
CV mode
Range: 0~15V
Setting Resolution: 0.1mV
Setting Accuracy (23±5℃): 0.01%+3mV
Readback Resolution: 0.1mV
Readback Accuracy (23±5℃): 3mV+2d
Voltage Settling Time: ≤10ms
Load Regulation: 0.01%+2mV
Line Regulation: 0.01%+0.2mV
Temperature Coefficient (0~40℃): 25ppm/℃
Voltage Ripple (20Hz-20MHz): 6mVrms
Current Measurement
Range 1
Range:-5~5A
Resolution: 0.1mA
Accuracy (23±5℃): 5mA+2d
Temperature Coefficient (0~40℃): 50ppm/℃
Range 2
Range:-500mA~500mA
Resolution: 0.01mA
Accuracy (23±5℃): 0.5mA+2d
Temperature Coefficient (0~40℃): 50ppm/℃
Range 3
Range:-1~1mA
Resolution: 0.1μA
Accuracy (23±5℃): 1μA+2d
Temperature Coefficient (0~40℃): 50ppm/℃
Current Protection Limit
Range: -5A~+5A
Current Limit Resolution: 0.1mA
Current Limit Accuracy (23±5℃): 5mA+2d
Temperature Coefficient (0~40℃): 50ppm/℃
Interface: LAN/RS232
AC Input: Single phase, 220V AC±10%, current <5A, frequency 47Hz~63Hz
Temperature: Operating temperature: 0℃~40℃, storage temperature: -20℃~60℃
Operating Environment: Altitude <2000m, relative humidity: 5%~90%RH(non-condensing), atmospheric pressure: 80~110kPa
Net Weight: Approx. 9kg
Dimension 2U, 88.0(H)*482.0(W)with handle*557.0(D)mm
