Current: 1A/CH
Voltage: 15V/CH
Power: 15W/CH
Channels: 24CH
CV Mode
Range: 0~15V
Setting Resolution: 0.1mV
Setting Accuracy（23±5℃): 0.01%+3mV
Readback Resolution: 0.1mV
Readback Accuracy ( 23±5℃): 0.01%+3mV
Temperature Coefficient（0~40℃): 20ppm/℃
Current Measurement
Range: 0~1A/0~1mA
Readback Resolution: 0.1mA/ 0.1μA
Readback Accuracy (23±5℃): 1mA+2d/ 1μA+2d
Temperature Coefficient (0~40℃): 30ppm/℃
Long-term Stability: 100ppm/1000h
Current Protection Limit
Setting value: 0~1A/ 0~1mA
Setting Resolution: 0.1mA/ 0.1μA
Setting Accuracy（23±5℃): 1mA+2d / 1μA+2d
Temperature Coefficient (0~40℃): 30ppm/℃
Long-term Stability: 100ppm/1000h
Load Regulation: 0.4mV
Isolation (Output to ground): 1000VDC
Isolation (Inter-channel): 500VDC
Communication Response Time: 10ms
Interface: LAN/RS232
AC Input: Single phase, 220V AC±10%, current <5A, frequency 47Hz~63Hz
Temperature: Operating temperature: 0℃~40℃, storage temperature: -20℃~60℃
Operating Environment: Altitude <2000m, relative humidity: 5%~90%RH(non-condensing), atmospheric pressure: 80~110kPa
Net Weight: Approx. 17kg
Dimension: 3U, 132.5(H)*482.0(W)with handle*559.0(D)mm
