Measurement range (actual distance): 7.5-1,090m/8-1,200 yd.
Distance display (increment):
Actual distance (upper): Every 1m/yd.
Actual distance (lower): Every 0.5m/yd.
Horizontal distance/Slope adjusted distance (lower): Every 0.2m/yd.
Height (upper):
Every 0.2m/yd. (shorter than 100m/yd.)
Every 1m/yd. (100m/yd. and over)
Accuracy* (actual distance):
±0.75m/yd. (shorter than 700m/yd.)
±1.25m/yd. (700m/yd. and over, shorter than 1,000m/yd.)
±1.75m/yd. (1,000m/yd. and over)
Magnification (x): 6
Effective objective diameter (mm): 21
Actual field of view (°): 7.5
Exit pupil (mm): 3.5
Eye relief (mm): 18.0
Dimensions (L x H x W) (mm/in.): 100 x 75 x 42/3.9 x 3.0 x 1.7
Weight (excluding battery) (Approx.) (g/oz.): 180/6.3
Power source: CR2 lithium battery x 1 (DC 3V)
Auto power shut-off (after approx. 8 sec. unoperated)
Waterproof structure:
Waterproof (up to 1m/3.3 ft. for 10 minutes), fogproof
Battery chamber is rainproof — JIS/IEC protection class 4 (IPX4) equivalent (under Nikon's testing conditions)
Laser classification: IEC60825-1: Class 1M/Laser Product FDA/21 CFR Part 1040.10: Class I Laser Product
Electromagnetic compatibility: FCC Part15 SubPartB class B, EU:EMC directive, AS/NZS, VCCI classB, CU TR 020, ICES-003
Environment: RoHS, WEEE
