Width: 4.4 mm
Height: 1.15 mm
Length: 5 mm
Shutdown: No Shutdown
Input Type: Rail-to-Rail
Technology: Bipolar
Output Type: Rail-to-Rail
Supply Type: Single
Unit Weight: 121.800 mg
Amplifier Type: Rail to Rail
Mounting Style: SMD/SMT
SR - Slew Rate: 3.5 V/us
THD plus Noise: 0.001 %
Voltage Gain dB: 85 dB
Number of Channels: 4 Channel
Supply Voltage - Max: 14 V
Supply Voltage - Min: 2.5 V
Pd - Power Dissipation: 520 mW
Ib - Input Bias Current: 350 nA
Operating Supply Current: 8 mA
Operating Supply Voltage: 3 V, 5 V, 9 V, 12 V
Vcm - Common Mode Voltage: 4 V
Ios - Input Offset Current: 100 nA
Vos - Input Offset Voltage: 6 mV
GBP - Gain Bandwidth Product: 10 MHz
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
en - Input Voltage Noise Density: 10 nV/sqrt Hz
CMRR - Common Mode Rejection Ratio: 60 dB
