Gain: 110 dB
Class: Other
Width: 3.5 mm
Height: 1.15 mm
Length: 4.4 mm
Shutdown: No Shutdown
Unit Weight: 23.400 mg
Amplifier Type: Dual Audio Amplifier
Mounting Style: SMD/SMT
SR - Slew Rate: 5 V/us
THD plus Noise: 0.0005 %
Number of Channels: 2 Channel
Description/Function: Dual Operational Amplifier for improving tone control
Supply Current - Max: 9 mA
Supply Voltage - Max: 18 V
Supply Voltage - Min: 2 V
Pd - Power Dissipation: 600 mW
Ib - Input Bias Current: 100 nA
Operating Supply Current: 6 mA
Ios - Input Offset Current: 5 nA
Vos - Input Offset Voltage: 300 uV
GBP - Gain Bandwidth Product: 15 MHz
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
CMRR - Common Mode Rejection Ratio: 110 dB
PSRR - Power Supply Rejection Ratio: 110 dB
