Leeb probe types: D, DC, DL, C, D+15, E, G
Measuring range for steel: HV:230~940; HRC:20~70; HB:90~650. Tensile strength, MPa 370~1740
Measuring accuracy: HV:±3%HV; HRC:±1.5%HRC; HB:±3%HB
Indenter: Hardened ball (Leeb)
Measuring direction: Any direction 360°
Data storage: Limited only by the memory card
Communication: Upload data to PC and export as a spreadsheet (USB cable and software included )
Hardness scale: HRC, HB, HV, HRB, HS, HL, MPa
Materials: Dynamic (Leeb) pre-calibrated for steel, alloy steel, cast iron, stainless steel, aluminum, bronze, brass, copper, Additional custom materials for calibration.
Data display: Angle (Leeb), Single test result, Max, Min, Average of tests, Number of tests, Deviation, Var. coeff, Histogram, Signal and Smart Mode (Filter of incorrect measurements).
Indication: Color LCD display (320×240)
Operating environment: Temperature:-20°C~40°C; Humidity: 30%~80%R.H.
Power supply: DC 4,5V (3 pcs batteries AA)
Instrument dimensions: 160x75x30mm
Net weight: Approx. 0.3kg (Without probe)
Battery life: Approx. 10 hours.
Standard package: Hardness tester, Leeb probe, 3 batteries, Charger, USB cable, Operating manual, Software for PC, Case
Option Rockwell Hardness Test Block HRC (HRA orHRB): 160 USD
Option Brinell Hardness Test Blocks HB: 300 USD
Option Vickers Hardness Test Blocks HV: 240 USD
Option Leeb Hardness Test Block (type D): 320 USD
Option Leeb Hardness Test Block (type G): 800 USD
Descriptions:
- The most popular method in the world for testing the hardness of metals using a portable hardness tester is the Leeb method (ASTM A956). The so-called dynamic method for determining hardness is widespread due to its ease of use. The user does not need to have special skills and or knowledge in the field of hardness measurement, to carry out the measurement, it is necessary to charge up the impact body of the device’s probe, install the probe on the tested surface, press the release button of the probe and the hardness value will be displayed on the device screen.
- This method is recommended for large products, weighing from 5 kg and a thickness of 10 mm and more, however, observing certain requirements for fixing the product, it is possible to measure also small parts.
The device can be equipped with a Bluetooth module!
- Do hardness measurements, calibrate the device, set up a convenient display of values, save the results of hardness measurements, synchronize the archive with your other devices and a PC, transfer measurement results to your colleagues – all this is available with your smartphone thanks to the special NOVOTEST app for Android.
- Using a Bluetooth connection, your smartphone connects to the hardness tester and you have a completely new device – a new generation hardness tester! The intuitive interface, ample opportunities for documenting results, Internet access, touch screen, camera, microphone and GPS receiver of a smartphone turn your hardness tester into something completely unique and previously inaccessible.
The main advantages of the Combined Hardness Tester NOVOTEST T-D3:
- Large full color graphic display with bright backlighting
- Various measurement modes: statistic, graph, histogram, smart, signal
- Calibration of any scale in any range
- Convenience and ease of measurement
- Optimized number of buttons
- 88 combinations of materials and hardness scales (calibrations)
- Photofixation of tested objects
- Extended temperature range (frost, down to – 40°C)
- Internal memory and communication with PC
- New, intuitive menu with tips on the buttons
- Optional wireless mini printer
- Water resistant case
- Rubber protected bumper
