Measurement Range: 0...1000 ppmV, 0...1, 0…25 %
Accuracy: +/- 3 ppm @ 100 ppm, +/- 1 ppm @ 10 ppm
Output Resolution (4...20 mA): 0.5 ppmV / 0.01 %
Lower Detection Limit (LDL): 1 ppmV (ppm ranges) / 0.01 % (% ranges)
Sample Flow Rate (application dependent)
Flow-through / extractive: 100...500 ml/min (250 ml/min optimal) in a vented atmosphere
Direct insertion: Up to 6 m/s
Pressure Range: 900…1100 mBarabs
Response Time (T90): < 15 seconds @ +25 °C (+77 °F) within selected range
Operating Temperature Range: 0…+45 °C (+32…+113 °F)
Life Expectancy (application dependent): Up to 18 months
Humidity: 0…95 %rh non-condensing (with normal use)
Shelf Life (in original packaging): Up to 3 months
Calibration Interval(application dependent): 3...6 months
Transmitter
Electrical
Output Signal: 4...20 mA
Digital Communications: RS485 Modbus
Electrical Interface: Industry standard M12
Power Supply: 24 V DC +/- 15 %
Maximum Power Consumption: 2.4 W
Cable Length: 1 meter (supplied as standard) / 3 meter / 10 meter
Mechanical
Ingress Protection: IP66
Housing Material: Chromated aluminum
Process Connection: Flow-through (1/8” NPT) or KF40 flange
Weight
Flow-through: 391g (13.8 oz)
Flow-through w/orifice: 393g (13.9 oz)
KF40: 397g (14.0 oz)
