Oceanus OC-850 Portable multi gas detector (CO, O2, H2S, LEL, CO2)

Applicable gas: LEL (CH4), O2, H2S, CO, CO2

Sensor Type:

- Catalytic combustion sensor for LEL

- Electrochemical sensor for O2, H2S and CO.

Measuring range:

LEL (CH4): 0~100% LEL

O2: 0~30% VOL

H2S: 0~100 ppm

CO : 0~1000 ppm

CO2 : 0-10000ppm

Display: Large LCD screen

Alarm storage: With alarm data storage function, users can review data from detector (9999 data stored)

Sampling mode: suction pump sampling (1L/min)s

Language: Customizable English or Chinese control menu

Explosion-proof index: Ex ia IIC T4

Protection level: IP66

Working environment:

Operating temperature: -40℃～70℃

Operating Humidity: 0-95%RH (non-condensing)

Size: 250*75*32mm

Weight: 300g
