Width: 45 mm
Height: 75 mm
Length: 110 mm
Weight: 270 g
Accuracy: ± 0.2 %
Mounting: DIN Rail 46277 and EN 50022
Approvals: CE, UL
Bandwidth: 1.5 Hz (-3 dB)
Isolation: 2000 Vrms
Materials: Polycarbonate, RAL 7032
Input Type: Voltage
Wire Gauge: 14 AWG
Overvoltage: 25 V
Output Value: Process
Output Detail: 4 to 20 mA and 0 to 10 Vdc standard; 0 to 20 mA via jumper select
Output Ripple: ≤0.5%
Output Signal: Current, Voltage
Response Time: ≤250 ms
Serial Number: Break Protection: Jumper selectable, upscale (>20 mA) or downscale (<4 mA)
Approvals Note: Enclosure: UL 94 V-1, Terminal Housing: UL 94-2
Supply Voltage: 220 Vac
Impedance Input: 100 kΩ
Number of Inputs: 1
Electrical Output: 4 to 20 mA
Enclosure Ratings: IP20, IP40
Power Consumption: max 1.5 VA
Supply Power Note: 110 Vac (standard); 220 Vac or 24 Vdc (optional) (±10% tolerance on all power supplies)
Supply Power Type: AC
Voltage Output Range: 0 to 10 Vdc
Temperature Coefficient: ≤0.015%/°C
Storage Temperature, Max: 80 °C
Storage Temperature, Min: -30 °C
Current Measurement Range: N/A
Voltage Measurement Range: 0 to 100 mV dc
Operating Temperature, Max: 60 °C
Operating Temperature, Min: -10 °C
Frequency Measurement Range: N/A
Temperature Measurement Range: N/A
