Reset: 0 to 50 repeats/min
Scale: Digital
Width: 192 mm
Height: 160 mm
Length: 103 mm
Offset: None
Weight: 1.4 kg
Accuracy: ± 3 °C (± 5.4 °F)
RTD Type: None
Input Type: Thermocouple
Form factor: Wall Mounted
Display Size: 20 mm (.78 in)
Display Type: 7 Digit LED
Accuracy Note: 1°C/°F for T/Cs and RTDs; 0.1°C/0.2°F for thermistors
Output Detail: 6 Relay Outputs, SPST; 1 A @ 28 Vdc or 0.5 A @ 120 Vac resistive;5 Vdc drive @ 50 mA max (internal 5 Vdc source)
Output Signal: None
Ramp and Soak: Multiple Ramp & Soak
Sampling Rate: 0 to 500 Hz (updates/second)
A/D Conversion: 20,000 count A/D converter
Control Output: 6 SPST Relay
Supply Voltage: 120 Vac
Conversion Rate: 7/s
Measuring Range: 470 to 1800°C
On/Off Deadband: 0 to FS
Measurement Type: Temperature
Number of Inputs: 1
Display Type Note: Red 7-segment LED display, 20 mm (0.8") H Display Test: 8.8.8.8.8.8.8. on power-up
Enclosure Ratings: IP65
Proportional Band: 0 to 100% of span
Supply Power Note: 120 Vac (60 Hz)—standard 220 Vac (50 Hz)—optional 15 Vdc @ 900 mA—optional
Supply Power Type: AC
Thermocouple Type: B
Enclosure Material: Polycarbonate
Sampling Rate Note: 0 to 500 sec, Variable, displayed as rate of change/time base
Electrical Connection: Screw Terminal
Number of Control Outputs: 6
Cold Junction Compensation: Error: ± 0.5°C @10 to 45°C
