Width: 48 mm
Height: 48 mm
Length: 89 mm
Offset: ± 5°C (Offset Accuracy)
Weight: 205 g
Accuracy: ± 0.25 %
Input Type: Thermocouple
Form factor: 1/16 DIN
Display Type: 2.5 Digit LCD
Accuracy Note: ± 0.25% over 90% of scale range (-50 to 950°C) and ± 1% over the extreme 5% of the scale limits (-99 to -51 and 950 to 999°C)
Memory Backup: EEPROM
Output Detail: Mechanical Relay;SPDT relay, rated @ 3 A, 240 Vac;Alarm Output-SPST N.O. relay, rated @ 3 A, 240 Vac
Output Signal: None
Control Output: SPDT Relay
Supply Voltage: 90 to 260 Vac
Measuring Range: Type J: -99 to 700°C Type K: -99 to 999°C Type T: -99 to 300°C Type N: -99 to 999°C
Measurement Type: Temperature
Number of Inputs: 1
Cutout Dimensions: 45 x 45 mm
Supply Power Note: 10 to 32 Vac/Vdc @ 60 mA maximum, 90 to 260 Vac, 50/60 Hz @ 1.5 Va maximum
Supply Power Type: AC
Additional Features 1: Alarm Output
Programmable Functions: alarm, °C/°F, control action, hysteresis, offset, password, sensor type, setpoint limits
Storage Temperature, Max: 85 °C
Storage Temperature, Min: -20 °C
Operating Temperature, Max: 50 °C
Operating Temperature, Min: -10 °C
