Alarm: With high and low alarms
Width: 96 mm
Height: 48 mm
Length: 166 mm
Weight: 0.65 kg
Form factor: Benchtop
Display Type: LED
Relay Output: 1 A @ 30 Vdc
Sampling Rate: 7 Hz (7 updates/second)
Data Interface: RS232
Supply Voltage: 110 Vac
Measurement Type: Temperature
Number of Inputs: 1
Cutout Dimensions: 45 x 92 mm
Display Type Note: 5-digit LED
Supply Power Type: AC
Data Interface Note: RS232C (protocol and sample programs included)
Temperature Accuracy: ± 0.01 K
Additional Features 1: Single input, 1⁄8 DIN, silicon diode monitor
Electrical Connection: Sub-D Female Miniature Connector
Number of Measurements: 8
Display Measuring Units: °C, °F, K, Ohm, V
Temperature Sensor Type: Silicon Diode or RTD
Process Temperature, Max: 800 K
Process Temperature, Min: 30 K
Operating Temperature, Max: 35 °C
Operating Temperature, Min: 15 °C
Temperature Display Resolution: 0.001°
