CMRR: 100 dB at 50/60 Hz
Drift: Zero: ±1 Count
Width: 2.794 mm
Height: 6.223 mm
Length: 9.144 mm
Memory: EEPROM
Accuracy: ± 0.02 %
Mounting: Spacing for mounting screws = 2.700" (6.858 cm).Screw threads = 6 X 32
Baud Rate: 300 to 115200
Materials: ABS
Input Type: Voltage
Protection: Input Protection: 250 Vac
Resolution: 0.0001
Calibration: Autozero, no adjustment pots
Sensor Type: N/A
Sampling Rate: 1 Hz (1 update/second)
Data Interface: RS485
Supply Voltage: 10 to 30 Vdc, 0.75 W
Analog I/O Note: Voltage: Input Ranges: ±100 mV, ±1 V, ±5 V, ±10 V, ±100 Vdc, Resolution: 0.01% of FS (4 digits), Accuracy: ±0.02% of FS max, Zero Drift: ±1 count maximum (autozero), Span Tempco: ±50ppm/°C maximum, Input Burnout Protection: To 250 Vac, Input Impedance: ≤ +1 V input = 100 MΩ min, ≥ +5 V input = 1 MΩ min
Conversion Rate: 8 conversions/sec
Impedance Input: >1 MΩ
Leakage Current: < 2 μA
Relative Humidity: 0 to 95% RH non-condensing
Supply Power Type: DC
Common Mode Voltage: Input to Output at 60 Hz: 500 V rms
Data Interface Note: Data Format: NRZ asynchronous; 1 start bit, 7 data bits, 1 parity bit and 1 stop bit Parity: Odd, even, none Address: User selectable address Protocol: ASCII format Multidrop Modules:Up to 30 per host serial port Communications: Distance up to 1219 m (4000') (RS-485) Transient Suppression: On RS-485 communication lines Communications Error:Checking via checksum
Electrical Connection: Screw Terminal
Temperature Coefficient: ±50 ppm/°C
Storage Temperature, Max: 85 °C
Storage Temperature, Min: -25 °C
Current Measurement Range: N/A
Number of Channels, Input: Analog: 4
Voltage Measurement Range: ±5 V
Operating Temperature, Max: 70 °C
Operating Temperature, Min: -25 °C
