Width: 96 mm
Height: 48 mm
Length: 120 mm
Weight: 225 g
Accuracy: ± 1.5 °C (± 2.7 °F) + 1 count
Input Type: Thermocouple
Resolution: 1.0°C
Form factor: 1/8 DIN
Display Size: 14.2 mm (0.56 in)
Display Type: 3.5 Digit Single LED
Reading Rate: 2.5 samples/sec
Analog Output: 1 mV/deg
Step Response: 1 sec
Supply Voltage: 115 Vac
Cutout Dimensions: 45 x 92 mm
Display Type Note: 3 1 ⁄2 digit LED, 14.2 mm (0.56") digits
Enclosure Ratings: IP65, NEMA Type 4
Power Consumption: 2 W
Supply Power Note: 115 Vac, ±15%, 50/60Hz Optional Power: 9 to 32 Vdc, non-isolated
Thermocouple Type: K
Additional Features 1: 230 Vac power
Operating Temperature, Max: 60 °C
Operating Temperature, Min: 0 °C
