Weight: 425 g
Accuracy: ± 1.5 °C (± 2.7 °F) + 1 count
Polarity: Bipolar
Input Type: Thermocouple
Resolution: 0.1°C
Calibration: IEC 584-1 (IPTS-68)
Form factor: 1/8 DIN
Front Bezel: 96 W x 48 H x 5.1 D mm
Display Size: 14.2 mm (0.56 in)
Display Type: 4.5 Digit LED
Reading Rate: 2.5 samples/sec
Analog Output: 1 mV/deg
Step Response: 1 sec
A/D Conversion: Dual-slope technique
Supply Voltage: 9 to 56 Vdc, 115 to 230 Vac
Noise Rejection: NMR, SIG HI to SIG LO: 70 dB, 50/60 Hz ;CMR, ANA GND to PWR GND: 120 dB, DC to 60 Hz ;CMV, ANA GND to PWR GND: 1500 Vp per HV test, 354 Vp per IEC spacing
Digital I/O Note: Level: TTL or 5V CMOS compatible
Cutout Dimensions: 45 x 92 mm
Display Type Note: Symbols: -1.8.8.8.8 Decimal Points: Four positions programmable by jumpers behind the lens or at connector Overrange Indication: Four least-significant digits flash
Enclosure Ratings: IP65, NEMA Type 4
Power Consumption: 3.7 W
Relative Humidity: 95% at 40°C (non-condensing)
Supply Power Note: AC Voltages: 115 or 230 Vac ±15% AC Frequency: 49 to 440 Hz DC Voltages: 9 to 32 Vdc, isolated to 300 Vp; 26 to 56 Vdc, isolated to 300 Vp Power Consumption: 2.5 W
Thermocouple Type: K
Depth Behind Panel: 104 mm
Enclosure Material: Polycarbonate
Input Configuration: Single-ended
Thermal Span Effect: ±0.01% of reading/°C
Lead Resistance, Max: Type K: 50 µdeg/deg/Ω, up to 2000 Ω, Current Break: 300 nA
Output Configurations: Analog Current/Voltage
Sensor Break Detection: Positive overrange (upscale)
Temperature Coefficient: ±0.05 deg/deg
Sensor/Transmitter Power: 4.7 Vdc and -4.7 Vdc ±5%, 10 mA max
Storage Temperature, Max: 85 °C
Storage Temperature, Min: -40 °C
Warm-Up to Rated Accuracy: 20 min
Operating Temperature, Max: 60 °C
Operating Temperature, Min: 0 °C
Output Configurations Note: Voltage: 1 mV/deg Calibration Error: ±1.5 mV on °C, ±2.7 mV on °F Current: 1 mA max Source Resistance: 68 Ω
Temperature Measurement Range: -105 to 1248°C
