Width: 46 mm
Height: 125 mm
Stability: Long-Term Stability: 0.25 % Fs/year
Display Type: 4 Digit LCD
EMC Standard: Anti-EMI Design, EN61326
Accuracy Note: ± 0.4%FS or ± 0.2%FS
Output Signal: Digital
Pressure Type: Gauge
Pressure, Max: 30 psi
Pressure, Min: 0 psi
Accuracy Class: 0.1% to 0.25%
Data Retention: EEPROM
Outer Diameter: 80 mm
Proof Pressure: 120% Full Scale
Number of Digits: 5
Electrical Output: USB
Materials, Wetted: 304 Stainless Steel
Pressure Accuracy: ± 0.2 %
Supply Power Type: Battery
Enclosure Material: 304 Stainless Steel
Media Compatibility: Alcohols, Argon, Compatible Gases, Compatible Liquids, Nitrogen, Oils, Water
Number of Batteries: 2
Sample/Display Rate: 10,000 points per 3 times/second
Battery Size and Type: Alkaline AAA
Process Connection Size: 1/4 in
Process Connection Type: NPT Male
Process Temperature, Max: 60 °C
Process Temperature, Min: 0 °C
Sample Display Rate Note: Up to 10,000 points per 3 times/second
Operating Temperature, Max: 70 °C
Operating Temperature, Min: -20 °C
