Display: No Display
Accuracy: ± 0.5 %
Output Note: Quadrature signals (A, B with 90° phase shift), Directional Output: Positive high (24V), negative low (0.8 to 1V), Error Output: Active high (24V), inactive low (0.8 to 1V), Signal Voltage Output: Vss = 9 to 27 Vdc (channel 1, channel 2, error/direction), Signal Output: Iout = 300 mA maximum at 24 Vdc (channel 1, channel 2)
Bearing Type: Hard metal
Accuracy Note: ±0.5% of measured value with viscosity of > 21 cSt
Output Detail: Iout = 300 mA maximum at 24 Vdc (channel 1, channel 2)
Repeatability: ±0.05%
Supply Voltage: 10 to 28 Vdc
Viscosity Range: 1000000 cSt
Housing Material: Cast Iron
Output Frequency: 0 to 100 kHz
Electrical Output: Amplified Square Wave
Enclosure Ratings: IP65
Power Consumption: 65 mA at 24 Vdc
Supply Power Note: u = 10 to 28 Vdc; reverse pole protection
Supply Power Type: DC
Media Compatibility: High Viscosity Liquids
Operating Pressure, Max: 6000 psi
Process Connection Size: 1 1/4 in
Process Connection Type: Flange
Volumetric Flow Rate, Max: 132 GPM
Volumetric Flow Rate, Min: 0.26 GPM
Operating Temperature, Max: 120 °C
Operating Temperature, Min: -30 °C
