Height: 6.16 in
Accuracy: ± 5 %
Diameter: 5.16 in
Mounting: Panel Mount
Scale Length: 65 mm
Air Flow, Max: 8.3 SCCM
Air Flow, Min: 0.83 SCCM
Repeatability: ± 0.25%
Valve Included: true
Number of Tubes: 1
Water Flow, Max: 0.98 SCCM
Water Flow, Min: 0.098 SCCM
Materials, Wetted: Borosilicate, PCTFE (Polychlorotrifluoroethylene), Perfluoroelastomer, PTFE, Sapphire
Media Compatibility: Air, Water
Mounting Orientation: Panel Mount
Center-to-Center Length: 2.56 in
Operating Pressure, Max: 100 psi
Process Connection Size: 1/8 in
Process Connection Type: NPT Female
Process Temperature, Max: 66 °C
