Scale: Direct Read
Accuracy: ± 5 %
Mounting: Panel Mount
Materials: 316 Stainless Steel, Aluminum, Polycarbonate
Back Plate: 1/8" thick white acrylics
Float Type: Carboloy
Valve Type: 6-Turn Valve
Scale Length: 65 mm
Repeatability: ± 0.25%
Turndown Ratio: 10:1
Valve Included: true
Number of Tubes: 1
Helium Flow, Max: 1.5 l/min
Helium Flow, Min: 0.15 l/min
Materials, Wetted: 316 Stainless Steel, Borosilicate, FKM, Tungsten Carbide
Media Compatibility: Hydrogen
Center-to-Center Length: 65 mm
Operating Pressure, Max: 200 psi
Process Connection Size: 1/8 in
Process Connection Type: NPT Female
Process Temperature, Max: 121 °C
Mounting Fittings In Contact With Fluids: 316 stainless steel, Aluminum, black anodized
