Scale: Direct Read
Length: 7.2 in
Accuracy: ± 2 %, ± 5% with transitional flow
Diameter: 2.375 in
Materials: Stainless Steel
Output Detail: 4 to 20 mA ouput (12 to 35 Vdc powered)
Output Signal: Current
Repeatability: ± 1%
Valve Included: false
Mechanical Life: >10^7 cycles
Water Flow, Max: 40 GPM
Water Flow, Min: 4 GPM
Materials, Wetted: Buna-N (NBR), EPR, FKM, Perfluoroelastomer, PTFE, Stainless Steel
Particle Size, Max: 76 μm
Media Compatibility: Hydraulic Oil, Light Oil, Oil
Additional Features 1: Dual Reading Scale
Operating Pressure Note: 410 bar (6000 psig) up to 116°C (240°F)
Operating Pressure, Max: 6000 psi
Process Connection Size: 1 in
Process Connection Type: NPT Female
Scale Media Calibration: Oil
Process Temperature, Max: 116 °C
Standard Calibration Fluid: DTE 25 @ 43°C (110°F), 0.873 sg
