Reset: Reset button or remote through “D” -connector, to disable relay or buzzer
Scale: Direct Read
Buzzer: User configurable
Accuracy: ± 2 %, ± 5% with transitional flow
Mounting: Panel Mount
Materials: 316 Stainless Steel
Float Type: 316 Stainless Steel
Alarm modes: High, High/Low, Low
Air Flow, Max: 7825 ml/min
Air Flow, Min: 782.5 ml/min
Repeatability: 0.50%
Response Time: 500 ms
Light Immunity: Pulse modulated
Supply Voltage: 15 Vdc
Valve Included: true
Number of Tubes: 1
Source of Light: 65 mm, Red LED
Water Flow, Max: 217 ml/min
Water Flow, Min: 21.7 ml/min
Materials, Wetted: 316 Stainless Steel, Borosilicate, FKM, Stainless Steel
Power Consumption: max 200 mA
Media Compatibility: Air, Water
Dry Contact Closures: 2 Normally Open, and Normally Closed Relays 91A, 30 Vdc Maximum
Digital Connector Type: 9 pin Sub-D
Operating Pressure, Max: 200 psi
Process Connection Size: 1/8 in
Process Connection Type: NPT Female
Operating Temperature, Max: 70 °C
Operating Temperature, Min: 0 °C
Alarm Electronics Enclosure: 51.1 x 76.2 mm
