Width: 2.68 in
Height: 2.6 in
Length: 3.74 in
Accuracy: ± 2 %
K-Factor: 0.612 pulses/ml
Approvals: CE
Cable Length: 25 ft
Pressure Type: Gauge
Supply Current: 10 mA max
Supply Voltage: 5 to 24 Vdc
Linearity Error: ±0.25%
Viscosity Range: 0.2 to 20 cSt
Cable Length Note: 7.5 m (25'), resistor required 10 kΩ recommended
Electrical Output: 5 Volt, open collector pulse
Materials, Wetted: FKM, Polypropylene, PTFE
Supply Power Note: 5 to 24 Vdc @ 10 mA maximum, 3-wire
Pressure Drop Note: 10 psid @ 50% flow, 26 psid @ 100% flow
Pressure Drop, Max: 10 psi
Media Compatibility: Oil, Solvents, Water
Repeatability Error: ±0.25%
Operating Pressure, Max: 80 psi
Operating Pressure, Min: 45 psi
Process Connection Size: 1/4 in
Process Connection Type: NPT Female
Volumetric Flow Rate, Max: 1.585 GPM
Volumetric Flow Rate, Min: 0.343 GPM
Operating Temperature, Max: 120 °C
Operating Temperature, Min: -30 °C
