Display: LCD
Accuracy: ± 0.5 %
Mounting: Pipe
Sensor Type: Reed Switch, Hall Effect
Display Note: Display: 7-digit/12 mm (0.47") upper, 7-digit/7 mm (0.28") lower all, Rate: User defined, Total: Resettable, Acc-Total: Non-resettable
Accuracy Note: ±0.5% of reading
Repeatability: ±0.03%
Flow Rate Note: < 5cPs (2.6 to 26) , > 5cPs (1.6 to 36)
Supply Voltage: 18 to 30 Vdc
Viscosity Range: 1000 cPs
Housing Material: PPS
Number of Digits: 7
Electrical Output: N/A
Enclosure Ratings: IP67, NEMA Type 6
Supply Power Note: Hall Effect Sensor Power : 4.5 to 24 Vdc, 7.5 mA , Reed Senseor Power : 30 Vdc, 500 mA
Supply Power Type: Battery
Media Compatibility: Corrosive Liquids
Electrical Connection: Stripped Leads
Operating Pressure, Max: 150 psi
Process Connection Size: 1 1/2 in
Process Connection Type: NPT Female
Volumetric Flow Rate, Max: 36 GPM
Volumetric Flow Rate, Min: 1.6 GPM
Operating Temperature, Max: 60 °C
Operating Temperature, Min: -20 °C
