Display: No Display
Accuracy: ± 0.5 %
Mounting: Pipe
Sensor Type: Reed Switch, Hall Effect
Cable Length: 3 ft
Accuracy Note: ±0.5% of reading
Repeatability: ±0.03%
Flow Rate Note: < 5cPs (4 to 62) , > 5cPs (2.6 to 66)
Supply Voltage: 18 to 30 Vdc
Viscosity Range: 1000 cPs
Housing Material: Polypropylene
Number of Digits: 7
Electrical Output: Amplified Square Wave
Enclosure Ratings: IP67, NEMA Type 6
Supply Power Note: Hall Effect Sensor Power : 4.5 to 24 Vdc, 7.5 mA , Reed Senseor Power : 30 Vdc, 500 mA
Supply Power Type: DC
Operating Pressure, Max: 1200 psi
Process Connection Size: 1 1/2 in
Process Connection Type: NPT Female
Volumetric Flow Rate, Max: 66 GPM
Volumetric Flow Rate, Min: 2.6 GPM
Operating Temperature, Max: 80 °C
Operating Temperature, Min: -40 °C
