Width: 1.5 in
Height: 3.5 in
Length: 4.5 in
Materials: Brass
Switch Type: SPST
Switch Rating: 26 VA
Pipe Size, Max: 0 in
Pipe Size, Min: 0 in
Enclosure Ratings: IP65
Switch Rating Note: 26 VA,20 W, 1A, 230 Vac/48 Vdc,
Media Compatibility: Liquids
Set Point Tolerance: ±15%
Electrical Connection: DIN 43650 A (solenoid valve)
Linear Flow Rate, Max: 0 ft/s
Linear Flow Rate, Min: 0 ft/s
Operating Pressure, Max: 362 psi
Process Connection Size: 1 in
Process Connection Type: NPT Female
Process Temperature, Max: 110 °C
Process Temperature, Min: 0 °C
Volumetric Flow Rate, Max: 4.4 GPM
Volumetric Flow Rate, Min: 3.5 GPM
Electrical Connection Note: Plug Connector: DIN 43650 form A/ISO 4400 cable socket with terminal screws, suitable for outer cable diameter 4.57 to 6.85 mm (0.18 to 0.27”)
Operating Temperature, Max: 80 °C
Operating Temperature, Min: 0 °C
Material Construction Option: N/A
