Width: 56 mm
Height: 16 mm
Length: 36 mm
Memory: 500000
Weight: 24 g
Spot Size: 8 mm (min)
Alarm Note: Programmable high and low limits; alarm is activated when temperature reaches or exceeds set limits
Stop Modes: Adjustable Delay Stop, Manual Through Software
Form factor: Desktop
Memory Note: 500,000 readings per channel (1,000,000 readings total) software configurable memory wrap 250,000 readings in multiple start/ stop mode
Samples,Max: 50000
Start Modes: Adjustable Delay Start, Immediate Start, Push-button
Battery life: up to 10 yr
Display Type: LED
Memory Modes: Yes
Field of view: 0.04236
Sampling Rate: 1 Hz (1 update/second)
Time Accuracy: ± 1 minute/month
Data Interface: USB
LED Indicators: Green LED Blinks: 10 second rate to indicate logging 15 second rate to indicate delay start mode; Red LED Blinks: 10 second rate to indicate low battery and/or full memory 1 second rate to indicate an alarm condition
Supply Voltage: 9 Vdc
Measurement Type: Temperature
Number of Inputs: 1
Supply Power Type: Battery
Sampling Rate Note: 1 reading every 2 seconds to 1 every 12 hours
Data Interface Note: USB (interface cable required); 115,200 baud
Real Time Recording: May be used with PC to monitor and record data in real time
Temperature Accuracy: ± 2.5 °C
Battery Size and Type: 3.6V Li-ion
Electrical Connection: Sub-D Female Miniature Connector
Software Compatibility: XP SP3/Vista/7 and 8 (32-bit and 64-bit)
Spectral Response Note: 6.5 - 14µ
Temperature Resolution: 0.1 °C
Temperature Sensor Type: Thermocouple Type K
Process Temperature, Max: 80 °C
Process Temperature, Min: -40 °C
Operating Temperature, Max: 70 °C
Operating Temperature, Min: -18 °C
Thermocouple Resistance, Max: 3000 Ω
Infrared Thermocouple Dimensions: 3.25 L x 1.80 cm Dia
