Height: 84 mm
Length: 122 mm
Memory: 262,143 Readings
Weight: 1134 g
Diameter: 32 mm
Software: Windows XP SP3 / Vista / 7 and 8 (32 and 64 - bit)
Approvals: CE
Baud Rate: 115200
Materials: Stainless Steel, Aluminum
Resolution: Pressure : 0.2 psi
Stop Modes: Adjustable Delay Stop
Calibration: Digital calibration through software and automatically recorded within device
Memory Note: 262,143 total readings; software configurable memory wrap
Start Modes: Delayed Start, Immediate Start
Battery life: up to 1 yr
Display Size: 72 mm (2.8 in)
Display Type: Backlit LCD
Accuracy Note: Calibration Accuracy : Pressure: 2% FSR, 0.25% @ 25°C typical; Time Accuracy : ±1 minute/month (at 20° to 30°C)
Pressure Type: Absolute
Pressure, Max: 5000 psi
Pressure, Min: 0 psi
Sampling Rate: 0.5 Hz (2 seconds between updates)
Time Accuracy: ±1 minute/month
Data Interface: USB
Humidity Range: 0 to 95% RH non-condensing
LED Indicators: Power, Status, Memory
Millivolt Range: N/A
Measurement Type: Pressure
Supply Power Type: Battery
Frequency Response: Pressure Response Time: 0.1 ms
Sampling Rate Note: 1 reading every 2 seconds to 1 every 24 hours
Calibration Accuracy: Pressure : 2%
Battery Size and Type: Alkaline AA
Number of Measurements: 1
Process Connection Size: 1/4 in
Process Connection Type: NPT Male
Operating Temperature, Max: 54 °C
Operating Temperature, Min: -20 °C
